Parameter Name | straight track | bend rail | |
Rated Loading (kg) | 500 | 500 | |
Maximum Height (m) | 45 | 22 | |
Horizontal Travel | Location Mode (X-axis) | laser ranging or bar code addressing | address by bar code |
Positioning (X-axis) Accuracy (mm) | ≤±5 | ≤±5 | |
Speed (m/min) | 240 | 160 | |
Acceleration (m/s²) | 0.5 | 0.5 | |
Lifting Platform Elevation | Load Capacity (kg) | ≤500 | ≤500 |
Hoisting Crane Depth （m） | ≤42 | ≤20 | |
Orientation (Y-axis) | laser ranging or bar code addressing | laser ranging or bar code addressing | |
Positioning (Y-axis) Accuracy (mm) | ≤±3 | ≤±3 | |
Speed (m/min) | 50 | 30 | |
Acceleration (m/s²) | 0.5 | 0.5 | |
Fork | location Mode | Absolute Encoder + Microswitch | Absolute Encoder + Microswitch |
Z-axis Positioning Accuracy (mm) | ±3 | ±3 | |
Deep Extension fork Speed (m/min) | 60 | 60 | |
Deep Extension Fork Acceleration (m/s²) | 0.5 | 0.5 | |
Fork Extension Range (mm) | as required | as required | |
High-speed Operation Noise (dB) | ≤75 | ≤75 | |
